About InsulTech

The patented InsulTech™ Insulated Concrete Masonry System (ICMS) is a complete thermally-broken, continuous-insulated system that delivers unmatched thermal performance in a masonry system rated at R-16.2 – far exceeding today’s most stringent code requirements.

The InsulTech system is comprised of five components in a single, preassembled 12 ¼” unit that dramatically improves installation efficiency: structural CMU, EPS insulation, air barrier, drainage plane, and veneer face. With both the structural block and exterior veneer available in both standard finishes and Trenwyth® architectural finishes, InsulTech outperforms other insulated CMU systems in both thermal performance and architectural flexibility. When your project calls for the ultimate in masonry thermal performance, look no further than InsulTech.

Contact us to learn more about the Insultech concrete masonry system.

Product Details

  • Insultech is the highest-performing insulated masonry system available on the market.
  • Installed as a complete assembly to improve installation efficiency – eliminating multiple passes needed to construct standard cavity walls or similar masonry systems.
  • BASF Neopor EPS molded insulation inserts give the assembled unit an effective R-value of 16.2 at 75° F
  • Meets 2018 IECC Energy Codes from Zones 1 through 7
  • Internal stainless-steel metal anchors molded into EPS inserts ensures strong connection to the structural wall, providing wind-load resistance and Fire Integrity™ for fire safety
  • Available in the full range of Trenwyth® finishes to deliver ultimate interior and exterior aesthetic flexibility.
  • Certified by the Florida Department of Business & Professional Regulation, #FL28455.

All dimensions displayed in inches as width x height
